Kuhn GMD 3123F

Pris exklusive moms

Compnay LOGO
Images27
Kuhn GMD 3123F Slåttermaskiner
Kuhn GMD 3123F Slåttermaskiner
Kuhn GMD 3123F Slåttermaskiner
FavoriteMarkera som favorit
shareDela
Save searchSpara sökning
Skriv ut

INFO

Produktgrupp
Slåttermaskiner
Märke / modell
Kuhn GMD 3123F
Tillverkningsår
2021
Uppställningsplats
Szabás, Somogy
Land
Ungern
Mascus ID
55980E7D

PRIS

Jämför i annan valuta

DETALJER

Drivtyp
Buren
Annan information
Kuhn GMD-3123F Mower The GMD 3123 F front mowers are an ideal choice for farmers looking for a lighter machine, who have a tractor around 80 HP. Its compact design and lighter weight allow it to be used on flat fields as well as on hilly terrain. The mower unit effectively follows the ground surface thanks to its +/- 12° pendulum joint movement. It is equipped with two swath deflectors as standard, so the average swath width is between 1.2 and 1.4 meters. The durability of the most important components of the mower bar is ensured by top-quality components: - Special disc bearings with double-row angular contact ball bearings; - Large-diameter, precision-machined forged steel gears with 3 teeth engaging simultaneously; - Forged and heat-treated discs on their entire surface; - Sliders made of hardened steel, with optional (screw-on) protective plate; - PROTECTADRIVE protection. Kuhn 3123 F Technical data: Year: 2021 Working width per mowing unit (m) 3.10 Overlap of cutting area of front/rear units (cm) 29 - 44 - 55 (GMD 8730) 30 - 50 (GMD 9530) Swath width (m)1.30 - 1.40 Swath formation 2 swath deflector discs Hanging device 3-point - Cat. 2 Alfalfa inserts PTO speed (rpm) Primary 1,000 PTO 1 3 / 8’’ - 6-rib, friction clutch Freewheel Integrated in side transmission Cutter bar OPTIDISC ELITE Number of carbide skid discs 7 Drive protection PROTECTADRIVE system Suspension Spring (mechanical) Ground following Pendulum type articulated suspension Transport width (m) 3.00 Side protection FLEXPROTECT flexible side protection Storage position Horizontal Lighting and indicator lights Standard Minimum PTO power requirement (kW/HP) 32 / 43 Tractor electrical requirement 1 7-pin Approximate weight (kg) 745 The machine was advertised by Agro Partner Magyarország Kft. The description is for information only. We reserve the right to make changes, errors and misspellings.Visa fler

Agro Partner Magyarország Kft.

Damjanich u. 15. A, 6724 Szeged Csongrád Ungern
