JCB 3 CX

Engine parameters: The engine model is JCB 3CX, with a rated power of 63kW and a rated speed of 2200 revolutions per minute Transmission parameters: The transmission model is JCB 3CX, the diameter of the hydraulic torque converter is 305 millimeters, and the torque conversion coefficient is 3. The driving speeds for each gear are: first gear 5.5/5.6 km/h, second gear 8.9/9.0 km/h, third gear 19.1/19.2 km/h, fourth gear 34.8/34.8 km/h Hydraulic system parameters: Hydraulic system capacity is 132 liters Fuel system parameters: Fuel tank capacity of 160 liters Machine parameters: The working weight is 7370 kilograms, length x width x height (in driving condition) is 5620 x 2360 x 3610 millimeters, and the wheelbase is 2170 millimeters. The front wheel specification is 12.5 × 18, and the rear wheel specification is 18.4 × 26. The steering diameter (with brakes) is 8.1/10.4 meters, and the steering diameter (without brakes) is 6.9/9.5 meters Loading end parameters: The bucket capacity is 1.0/1.1 cubic meters (universal loading bucket) or 1.0 cubic meters (six in one loading bucket). The maximum unloading height is 2740/2720mm, and the maximum unloading distance is 830mm These parameters provide detailed specifications and performance indicators for the JCB 3CX excavator loader, helping users better understand and use the equipment.
